ABB DSQC609 3HAC14178-1 PBSE5117 Industrial Robot Power Supply Module

Functional Features

• Wide Adaptability and Stability: It supports global power grid voltage input (AC 85-264V) and can automatically identify and adapt to power supply standards in different regions. The combination of PWM modulation technology and LC filter circuits ensures output ripple of less than 50mVrms, guaranteeing stable I/O signal transmission for robots. It can operate continuously without faults for 18 months even in environments with ±15% voltage fluctuations.
• Redundancy and Hot-Swappable: It supports N+1 redundant configuration, enabling multiple power supplies to work in coordination through parallel current-sharing resistors. In case of a primary power supply failure, the backup power supply can seamlessly take over within 5ms to prevent robot downtime. The hot-swappable function allows module replacement without interrupting system operation, reducing maintenance time to 1/3 of that required for traditional power supplies.
• Intelligent Diagnosis and Energy Efficiency: Built-in LED status indicators display real-time input/output voltage, load current, and fault codes, and it supports remote monitoring of power supply health status via the IRC5 controller. The module automatically enters energy-saving mode under light loads (<30%), reducing power consumption by 40% and complying with EU ErP energy efficiency standards.
• Compact and Easy Installation: Its compact structure saves installation space, and the DIN rail mounting design enables quick and convenient installation. It can be directly replaced with similar products, simplifying system modification and expansion processes.
• Strong Compatibility: It is compatible with the ABB robot controller series and can be used with various robot models to provide stable power for controllers and peripheral devices.

Application Scenarios

• Automotive Manufacturing Industry: In body welding lines, it supplies power to welding robot servo motors, welding gun controllers, and vision sensors, ensuring precise control of welding parameters. Redundant design guarantees 100,000 consecutive welding operations without quality defects, increasing welding qualification rates to 99.8%.
• Electronic Assembly and Semiconductor: In chip packaging equipment, it provides stable 24V power for high-precision robotic arm vacuum suction cups, pick-and-place tools, and AOI inspection systems, supporting micron-level positioning accuracy (±5μm). After adopting this module, a semiconductor factory reduced equipment failure rates from 3 times per month to 0.5 times, increasing production capacity by 30%.
• Logistics and Warehouse Automation: In AGV navigation systems, it powers laser radars, drive motors, and communication modules, supporting cold start at -20°C and continuous operation in high-temperature environments up to +60°C. In an intelligent warehouse application, the module operated stably for 2 years in an environment with a dust concentration of 10mg/m³, extending the maintenance cycle to 12 months.
• Food and Pharmaceutical Industry: In aseptic filling production lines, its IP20 protection design and fanless heat dissipation structure meet GMP cleanroom requirements, providing reliable power for filling valves, labeling machines, and CIP cleaning systems. A pharmaceutical company shortened equipment validation cycles from 4 weeks to 72 hours after using this module.
• Other Fields: It is also applicable to packaging machinery, plastic machinery, printing equipment, wind power systems, and power automation equipment, providing stable power support for their normal operation.
