ABB CI858K01 Drive Bus Interface Module

Technical Specifications

  • Communication Protocols: Support Profibus DP/DPA2, Modbus TCP/IP, Ethernet/IP, PROFIBUS, PROFINET, EtherCAT, RS-232/RS-485.
  • Communication Rate: Up to 100 Mbps; the Ethernet interface supports 10/100 Mbps adaptive.
  • Hardware Interface: Integrate dual-port RJ45 Ethernet interface, support D-sub 9-pin serial port (RS-485/RS-232 optional); some models have 8 ports; the interface type includes DriveBus.
  • Operating Voltage: 24V DC (±10%).
  • Power Consumption: ≤5W.
  • Operating Temperature Range: -40°C to +70°C; some models have ranges such as -25°C to +60°C, 0°C to +55°C, -20°C to +60°C, -40°C to +60°C.
  • Storage Temperature Range: -40°C to +85°C.
  • Protection Level: IP20; some models reach IP65.
  • Dimensions: 70mm x 100mm x 35mm, 120mm x 120mm x 60mm, etc.
  • Weight: Approximately 0.2kg, 0.5kg, etc.
  • Certifications: Pass CE, UL, CCC international certifications; comply with IEC 61131-2 industrial equipment electrical specifications.
Category:
Description

Functional Features

  • Multi-protocol Support: Be compatible with a variety of mainstream industrial communication protocols, and can flexibly select appropriate protocols according to different application scenarios to realize data interaction and protocol conversion between different devices and systems.
  • High Reliability: Adopt industrial-grade design with strong anti-interference ability; have redundant power input design to improve system stability; can operate stably in harsh industrial environments.
  • Easy Installation and Maintenance: Adopt modular design, which is convenient for installation and maintenance; support DIN rail installation; can be quickly integrated into the existing system.
  • Flexible Configuration: Provide a variety of configuration options, which can be flexibly configured according to different application requirements; parameters can be set through configuration software.
  • Safety and Reliability: Have a variety of safety functions to ensure the safety of data transmission.
  • Fault Diagnosis: Have fault diagnosis function, and some models are equipped with built-in LED status indicators (red/green dual-color) + Web diagnosis interface to facilitate maintenance personnel to quickly locate faults.

Application Scenarios

  • Industrial Automation System Integration: Connect distributed I/O devices to realize multi-controller cooperative control; connect sensors and actuators to PLC or DCS; share data between multiple controllers.
  • Drive Control System: It is used in the drive bus interface of ABB steel mill drive system and paper machine control system to connect different drive devices to realize centralized control and management of these devices; it is applied to the drive control system to integrate the frequency converter into the complex drive control system.
  • Intelligent Factory Upgrade: Adapt to the Industrial Internet of Things (IIoT) architecture, support OPC UA data intercommunication; realize multi-axis servo synchronous control through the EtherCAT protocol.
  • Energy and Infrastructure: Be applied to the power SCADA system, power monitoring system, power generation and distribution system, and realize the communication of IED equipment in medium and high voltage substations.
  • Specific Industry Applications: Be widely used in process industries such as petrochemical industry and metallurgy; mechanical manufacturing fields such as automobile manufacturing and machine tools; water treatment fields such as sewage treatment and tap water; and building control fields such as air conditioning and ventilation in intelligent buildings.
