ABB AFC094AE02 HIEE200130R0002 Industrial Programmable Controller Module

Based on comprehensive analysis of ABB technical documentation and verified sources, the ABB AFC094AE02 is a multi-functional industrial module primarily serving as an ARCnet Control Panel, with significant contradictions in technical descriptions across sources. Below is a consolidated technical profile validated against manufacturer-aligned data:

Category:
Description

I. Core Technical Specifications

Parameter Primary Profile (ARCnet Control Panel) Contradicted Profiles
Electrical Input Voltage: 24 V DC (±20%) • 380V AC ()
Power Consumption: ≤10W • 230V AC ()
Physical Dimensions: 200×150×50 mm () • 85×72×66 mm ()
Weight: 1.0–1.5 kg • 0.25 kg ()
Operating Temp.: -20°C to +60°C • -10°C to +40°C ()
Protection: IP65 (Dust/Waterproof) • IP20 ()
Performance Display: 7-inch Color LCD () • No display ()
Communication: ARCnet, RS-485 • Profibus/Modbus TCP ()
I/O: 8 indicators + 12-key keypad • 16 analog/digital I/O ()

II. Functional Features

  1. ARCnet Network Management
    • Centralized control for ARCnet-connected devices (PLCs, sensors, drives) .
    • Real-time data exchange with ≤100ms latency for industrial networks .
  2. Human-Machine Interface (HMI)
    • Interactive LCD for parameter visualization, alarm management, and manual overrides .
    • Preconfigured function keys for rapid process control .
  3. Industrial Resilience
    • Vibration resistance (5g @ 10–500Hz) and fanless operation for harsh environments .
    • Conformity with IEC 60068 standards for shock/EMI protection .
  4. System Integration
    • Compatible with ABB 800xA, AC500, and third-party DCS/PLCs .
    • Hot-swappable design for zero-downtime maintenance .

III. Application Scenarios

Industry Primary Use Cases Key Contribution
Industrial Automation • Production line monitoring (automotive, textiles) Centralized ARCnet device control
• Robotic cell supervision Real-time fault diagnostics
Energy Management • HVDC transmission monitoring Grid stability visualization
• Power plant reactor control SIL 2-compliant safety interlocks
Process Industries • Chemical batch process control Parameter tuning via HMI
• Water treatment plant operations Flow/pressure setpoint adjustment
Building Automation • HVAC system optimization Energy consumption analytics

IV. Critical Data Contradictions & Resolutions

Conflict Area Misattributed Claim Verification Result
Product Identity “0.75kW AC Drive” () Incorrect: Matches ACS500 series drive specs, not AFC094AE02 .
“9A Circuit Breaker” () Incorrect: Refers to S200 series breaker .
“8-Channel Analog Module” () Incorrect: Aligns with ABB AI890 I/O module .
Communication Protocol “Ethernet/Modbus TCP” () Partially valid: Optional via expansion; native support is ARCnet/RS-485 .

V. Procurement Guidance

  • For ARCnet Control: Verify suffix HIEE200130R0002 ().
  • Exclude Incompatible Claims:
    • Drive functionality → Refer to ACS500 series (e.g., ACS550-01-072A-4).
    • Analog I/O → Use AI890/AO890 modules.
  • Environmental Compliance: Confirm -20°C operation (industrial variant) vs. commercial-grade (0°C) .
