ABB AC800PEC PCD237A101 3BHE028915R0101

• I/O Capacity: Scalable through ABB’s I/O systems, supporting digital/analog signals, encoders, and high-speed counters.
• Dimensions: 150 mm (L) × 100 mm (W) × 450 mm (H).
• Weight: 2.8 kg.
• Environmental: IP30 rating, -20°C to +60°C operating temperature (extendable to +70°C).

Key Features

• High-Speed Control: Dual-core architecture separates fast control tasks (FPGA-based, nanosecond-level) from standard PLC functions, ensuring precision in dynamic processes.
• Unified Programming: Uses ABB Control Builder M (IEC 61131-3, MATLAB/Simulink) for model-based design, bridging simulation and deployment.
• Seamless Integration: Fully compatible with ABB Ability™ System 800xA for centralized monitoring and control.
• Robust Hardware: Industrial-grade design with 4000 V lightning protection, 1.5 A overcurrent, and 600 W surge resistance.
• Flexible Configuration: Supports FPGA-based protocol embedding (e.g., custom communication without additional processor load).
• Diagnostic Tools: Built-in event logging, voltage/current monitoring, and predictive maintenance functions.

Application Scenarios

• Power Generation:
  • Controls synchronous generator excitation systems (e.g., UNITROL 6000 X-power) for stable voltage and reactive power distribution.
  • Manages large-scale rectifiers in aluminum smelting, electric arc furnaces, and renewable energy systems.
• Industrial Automation:
  • Optimizes motion control in CNC machinery, robotics, and conveyor systems.
  • Enhances process efficiency in petrochemical, pharmaceutical, and food/beverage production.
• Energy Infrastructure:
  • Stabilizes grid-connected inverters for solar/wind farms.
  • Supports high-voltage DC (HVDC) transmission and reactive power compensation.
• Critical Systems:
  • Ensures uninterrupted operation in water treatment, district heating, and emergency power supplies.

Advantages

• Performance: 100 μs cycle time enables sub-millisecond response for high-speed applications.
• Reliability: Industrial-grade components withstand EMC interference, vibrations, and extreme temperatures.
• Scalability: Modular design allows easy expansion of I/O and communication interfaces.
• Cost Efficiency: Reduces development time via MATLAB/Simulink integration and reusable code libraries.
• Global Support: Backed by ABB’s worldwide service network, ensuring 24/7 technical assistance.
