ABB 3BHB003041R0101 UFC719AE01 Communication Module

Technical Specifications
  • Communication Protocol: Supports Masterbus 300.
  • Number of I/O Modules: Up to 16.
  • I/O Types: Includes analog and digital inputs and outputs, temperature sensors, and motor controllers.
  • Power Supply: 24V DC (not explicitly mentioned in the search results, but commonly used…
Category:
Description
Product Introduction
  • The ABB 3BHB003041R0101 UFC719AE01 is a dedicated communication module designed for ABB’s industrial control systems, primarily Advant and Symphony distributed control systems (DCS). It acts as a critical communication bridge between the DCS controller and external devices, networks, or subsystems, enabling seamless data transmission and protocol conversion. The module is engineered to meet the high reliability and real-time performance requirements of industrial environments, ensuring stable communication for critical process control and monitoring tasks.
Technical Specifications
  • Communication Protocols Supported:
    • Native support for ABB’s proprietary protocols (e.g., Advant Fieldbus, Symphony I/O Bus)
    • Compatibility with standard industrial protocols (e.g., Modbus RTU/TCP, PROFIBUS DP)
  • Communication Ports:
    • 2 x Ethernet ports (10/100 Mbps, RJ45) for TCP/IP communication
    • 1 x RS485 serial port for Modbus RTU or PROFIBUS DP communication
    • 1 x proprietary fieldbus port (for connection to Advant/Symphony system backplane)
  • Power Supply:
    • Input voltage: 24 VDC (nominal); operating range: 19.2 VDC – 30 VDC
    • Power consumption: 5 W (typical), 7 W (maximum)
  • Operating Environment:
    • Operating temperature: -10°C – +55°C
    • Storage temperature: -40°C – +70°C
    • Relative humidity: 5% – 95% (non-condensing, at 40°C)
    • Vibration resistance: 5 Hz – 150 Hz, 0.15 mm amplitude (IEC 60068-2-6)
    • Shock resistance: 15 g acceleration, 11 ms duration (IEC 60068-2-27)
  • Isolation:
    • Port-to-port isolation: 1500 VAC (rms) for 1 minute
    • Signal-to-ground isolation: 1000 VAC (rms) for 1 minute
  • Dimensions: 120 mm (width) × 180 mm (height) × 200 mm (depth) (approximate, per module housing)
  • Mounting: Plug-in installation on Advant/Symphony DCS system racks (compatible with standard system enclosures)
Function Features
  • Multi-Protocol Support: Integrates support for both ABB proprietary and industry-standard protocols, eliminating the need for additional protocol converters and simplifying system integration.
  • Real-Time Data Transmission: Ensures low-latency data exchange (≤ 10 ms for critical signals) between the DCS and external devices, meeting the real-time requirements of industrial process control.
  • Redundant Communication: Supports dual…
