ABB

Technical Specifications

• Brand: ABB
• Origin: The United States
• Ordering Number: 3BSE026055R1
• Number of Units on CEX Bus: 12
• Connector: Miniribbon (36-pin)
• Power Consumption: Typical 120mA at 24V
• Operating Temperature: 55°C
• Protection Level: IP20 (compliant with EN60529 and IEC 529)
• Dimensions (Height x Width x Depth): Approximately 18.5cm x 5.9cm x 12.75cm
• Weight: 0.7kg
• Shipping Weight: 1.5kg
• Warranty Period: One year
• Reusable I/O Installations: Most existing I/O installations can be reused, including terminations and field wiring in existing ABB masters and Advant OCS devices
• Connection Capacity: Can connect to S100 I/O units in up to five I/O racks; a single CI20 can connect to up to 100 S856 I/O racks, with each I/O rack capable of accommodating multiple I/O boards

Technical Specifications

• Communication Protocols: Support Profibus DP/DPA2, Modbus TCP/IP, Ethernet/IP, PROFIBUS, PROFINET, EtherCAT, RS-232/RS-485.
• Communication Rate: Up to 100 Mbps; the Ethernet interface supports 10/100 Mbps adaptive.
• Hardware Interface: Integrate dual-port RJ45 Ethernet interface, support D-sub 9-pin serial port (RS-485/RS-232 optional); some models have 8 ports; the interface type includes DriveBus.
• Operating Voltage: 24V DC (±10%).
• Power Consumption: ≤5W.
• Operating Temperature Range: -40°C to +70°C; some models have ranges such as -25°C to +60°C, 0°C to +55°C, -20°C to +60°C, -40°C to +60°C.
• Storage Temperature Range: -40°C to +85°C.
• Protection Level: IP20; some models reach IP65.
• Dimensions: 70mm x 100mm x 35mm, 120mm x 120mm x 60mm, etc.
• Weight: Approximately 0.2kg, 0.5kg, etc.
• Certifications: Pass CE, UL, CCC international certifications; comply with IEC 61131-2 industrial equipment electrical specifications.

• Dimensions: 127.5 mm (length) × 18.5 mm (height) × 59 mm (width)
• Weight: 0.55 kg
• Operating Voltage: 24 V DC (supplied via CEX bus, no external power required)
• Power Consumption: Typically less than 4 W
• Operating Temperature: -40°C to +85°C (wide temperature range option available)
• Storage Temperature: -40°C to +80°C
• Relative Humidity: 0-95% (non-condensing)

• Communication Protocol Support: The CI867K01 supports redundant communication over optical fiber networks, operating within ABB’s High Speed Ethernet (HSE) architecture. It is compatible with the IEC 61850 standard for substation automation and integrates with redundant network topologies.
• Network Interface: Features dual redundant fiber optic ports for establishing high-speed, noise-immune communication links, typically operating at 100 Mbps.
• Redundancy: Designed for use in redundant system configurations, supporting Automatic Standby Switching (ASS) to ensure uninterrupted data transmission in case of network or hardware failure.
• Data Transfer Rate: Provides high-speed data transfer capabilities suitable for time-critical control and monitoring applications.
• Power Supply: Operates on standard 24 VDC industrial power, with low power consumption and high electrical isolation to enhance system safety.
• Environmental Specifications: Rated for operation in industrial environments with an extended temperature range, typically from -20°C to +70°C, and high resistance to electromagnetic interference (EMI).
• Mounting: Designed for DIN rail mounting, compatible with standard control cabinet installations.

• Communication Specifications
  • Channels: 2 independent channels.
  • Transmission Speed: Channel 1 supports 10/100 Mbit/s full-duplex; Channel 2 supports 10 Mbit/s half-duplex.
  • Device Capacity: The total number of devices supported by the two channels can reach 70 slaves and 8 masters.
  • Protocol: Supports Modbus TCP protocol, and integrates Modbus RTU with standard Ethernet TCP.
  • Interface Type: 2 RJ45 interfaces.
