ABB

• It is part of the HiPak or StakPak series, which are known for their robust design suitable for demanding environments.
• The semiconductor junction temperature (Tj) is an important parameter considered in the thermal limits for operation, ensuring reliable performance under various conditions.
• Thermal models for HiPak, StakPak, diodes, and IGCTs are available in XML format for accurate simulation using software like PLECS.

• Measurement Parameters:
  • Pressure range: 0–10 bar (gauge pressure, typical); compatible with absolute pressure (0–10 bar abs) or differential pressure (0–5 bar ΔP) configurations
  • Accuracy: ±0.1% of full scale (FS) at 25°C; ±0.2% FS over operating temperature range
  • Resolution: 0.01% FS (minimum detectable pressure change)
  • Long-term stability: ≤±0.1% FS per year
• Electrical Output:
  • Standard output signal: 4–20mA DC (two-wire system)
  • Optional output: 0–10V DC (three-wire system) or digital signals (HART 7.0 protocol for remote configuration)
  • Power supply: 12–36V DC (two-wire system); 18–30V DC (three-wire system)
  • Power consumption: Maximum 20mA (at 36V DC, two-wire system)
• Environmental Ratings:
  • Operating temperature: -40°C – +85°C (for liquid/gas media); -20°C – +60°C (for vapor media)
  • Storage temperature: -40°C – +100°C
  • Relative humidity: 0% – 95% (non-condensing, no dew formation)
  • Protection class: IP65 (hazardous area models: ATEX II 1G Ex ia IIC T4 Ga, IECEx Ex ia IIC T4 Ga)
  • Vibration resistance: IEC 60068-2-6, 10–500 Hz, 2g acceleration (operating)
  • Shock resistance: IEC 60068-2-27, 50g acceleration, 11ms duration (half-sine wave, non-operating)

Technical Specifications

• Core Parameters
  • CPU Speed: 2.4GHz
  • I/O Points: 512
  • Storage Capacity: 4GB
  • Protection Level: IP67
  • Safety Level: SIL3
• Power Supply
  • Rated Voltage: 240V AC
  • Power Supply Mode: 24V DC
• Communication
  • Protocols: Ethernet/IP, PROFIBUS DP, RS-232, RS-485
• Physical Characteristics
  • Dimensions: 192mm x 64mm x 35mm
  • Weight: 0.5kg
  • Installation Method: Rack-mounted
• Operating Environment
  • Operating Temperature Range: -40°C to 85°C
  • Current Range: 0.1A - 10A

Technical Specifications

• Input Signal Types: Supports multiple standard analog input signals, including 4-20 mA DC (current), 0-10 V DC (voltage), and ±10 V DC (bipolar voltage)
• Number of Input Channels: 8 independent analog input channels (isolated between channels to prevent signal interference)
• Input Resolution: 16-bit ADC (Analog-to-Digital Converter) for high-precision signal conversion
• Accuracy:
  • For 4-20 mA DC: ±0.1% of full scale (FS) at 25°C (ambient temperature)
  • For 0-10 V DC/±10 V DC: ±0.1% of full scale (FS) at 25°C (ambient temperature)
• Isolation:
  • Channel-to-channel isolation: 500 V AC (rms) for 1 minute
  • Module-to-backplane isolation: 1500 V AC (rms) for 1 minute
• Operating Temperature Range: -25°C to +60°C (storage temperature: -40°C to +85°C)
