GE IS220PTURH1A
Technical Specifications:
- Supply Voltage:ย Typically powered from the system backplane, 24 V DC nominal
- Power Consumption:ย Low power draw suitable for continuous operation
- Operating Temperature:ย 0ยฐC to +60ยฐC
- Storage Temperature:ย -40ยฐC to +85ยฐC
- Humidity Range:ย 5% to 95% relative humidity, non-condensing
- Relay Outputs:ย Multiple high-reliability relays for trip and alarm signaling
- Input Compatibility:ย Accepts discrete and analog inputs from sensors and other control modules
- Communication Interfaces:ย Integrated with the Speedtronic Mark VI system through backplane connections
- Certifications:ย UL, CE, and other relevant industrial certifications ensuring safety and reliability standards are met
- Mounting:ย Rack-mounted within the Speedtronic Mark VI system cabinet
Woodward PEAK200-HVAC 8200-1501
Technical Specifications:
- Model Number:ย 8200-1501
- Controller Type:ย Digital microprocessor-based HVAC controller
- Supply Voltage:ย 24 V AC ยฑ 10%, 50/60 Hz
- Power Consumption:ย Less than 15 VA
- Operating Temperature:ย 0ยฐC to +50ยฐC
- Storage Temperature:ย -25ยฐC to +70ยฐC
- Humidity Range:ย 5% to 95% relative humidity, non-condensing
BENTLEY 3500/65 145988-02
Technical Specifications:
- Module Type:ย Keyphasor and Speed Monitoring Module
- Part Number:ย 145988-02
- System Platform:ย Bently Nevada 3500 Series Rack
- Input Channels:ย Accepts signals from one or two Keyphasor or speed sensors (configurable)
- Sensor Compatibility:ย Compatible with Bently Nevada proximity probes (e.g., 3300 series) and other active or passive speed sensors
- Frequency Range:ย 0.1 Hz to 20,000 Hz (suitable for low-speed to high-speed machinery)
- Speed Measurement Accuracy:ย ยฑ0.05% of reading
SAACKE FSC-01
Technical Specifications:
- Supply Voltage:ย 24 V DC (typical), with options for 110โ230 V AC in certain configurations
- Power Consumption:ย Low power draw, optimized for continuous operation
- Operating Temperature:ย -10ยฐC to +55ยฐC
- Storage Temperature:ย -25ยฐC to +70ยฐC
- Humidity Range:ย 5% to 95% relative humidity, non-condensing
- Protection Rating:ย IP20 (suitable for indoor panel mounting)
- Input Compatibility:ย Accepts signals from flame detectors including UV, IR, and ionization sensors
- Output Relays:ย Equipped with safety-rated relay outputs for burner activation, alarm signaling, and system shutdown
PARKER AR-04AE-13574
BENDER IRDH575B1W-435
Technical Specifications:
-
- Rated Voltage:ย Up to 690 V AC, 24โ300 V DC
- Measuring Range:ย 0 to 999 kฮฉ (depending on voltage level)
- Response Time:ย Rapid detection time for insulation faults
- Operating Temperature:ย -10ยฐC to +60ยฐC
- Storage Temperature:ย -25ยฐC to +70ยฐC
- Humidity Range:ย 0% to 95% relative humidity, non-condensing
- Communication Interfaces:ย RS-485, Modbus RTU, Ethernet interface for network integration
- Display:ย LCD display for status indication and parameter setting
GE PQMII-T20
Technical Specifications:
- Measurement Standards:ย IEC 61000-4-30 Class A compliant for power quality monitoring
- Voltage Inputs:ย 3-phase or single-phase configurations, typical ranges up to 690 V AC
- Current Inputs:ย Compatible with Rogowski coils, CTs (current transformers), or clamp sensors
- Sampling Rate:ย High-speed sampling for transient and waveform capture
- Frequency Range:ย 45 Hz to 65 Hz (extendable for special applications)
- Voltage Accuracy:ย ยฑ0.1% of reading
- Current Accuracy:ย ยฑ0.5% of reading
- Harmonic Analysis:ย Up to 63rd harmonic for voltage and current
DEIF DLQ144-PC-NB
Technical Specifications:
- Supply Voltage:ย 24 V DC (standard industrial voltage)
- Power Consumption:ย Low consumption suitable for energy-efficient applications
- Operating Temperature:ย -25ยฐC to +70ยฐC, ensuring performance in diverse environments
- Storage Temperature:ย -40ยฐC to +85ยฐC
- Humidity Range:ย 5% to 95% relative humidity, non-condensing
- Communication Protocols:ย Supports Modbus RTU, Modbus TCP, and other standard protocols for integration with SCADA systems
- Dimensions (WxHxD):ย Compact design suitable for mounting in switchgear cabinets or control panels
- Certifications:ย CE, UL, and other relevant industry standards
